DC Voltage/Current Source

Get a Price/Quote

MOQ : 1 Unit

DC Voltage/Current Source Specification

Pressure
Atmospheric Pressure Operation

Accuracy
±0.5%

Resistant Feature
Corrosion Resistant Coating

Usage & Applications
Laboratory Testing, Educational Purposes, Industrial Calibration

Batteries Type
Not Required (Mains Powered)

Product Type
Current Source

Material
Mild Steel

Measuring Voltage Range
0-30V DC

Operating Temperature
0°C to 50°C

Frequency (MHz)
DC (0 Hz)

Insulation Box
Provided for Safety

Protection System
Fuse Protected Circuitry

Size
Standard

Color
White and Blue

Dimension (L*W*H)
305 x 205 x 135 mm

Weight
5 Kilograms (kg)

Input Supply Voltage
230V AC, 50Hz

Connector Type
Banana Plug Compatible

Display Type
Digital LED Display

Operating Mode
Constant Voltage/Current Mode

Front Panel
Powder Coated with Marked Scale

Output Terminals
4mm Safety Sockets

Overload Protection
Automatic Cut-off

Output Current Range
0-10A DC

Output Regulation
Line and Load Regulation < 0.05%

Cooling
Ventilated Body

Mount Type
Table-Top

DC Voltage/Current Source Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Delivery Point (DP), Cash in Advance (CID)

Supply Ability
1 Unit Per Day

Delivery Time
8 Week

Packaging Details
Box.

Main Domestic Market
All India

DC Voltage/Current Source About

DC Voltage/Current Source

The GS200 is a low voltage/current DC source with high accuracy, high stability, and high resolution. With its excellent traceability, stability, and 5 1/2-digit resolution, the GS200 generates extremely low-noise DC voltage and current signals that are required for many applications. Additionally, the optional monitoring feature turns the GS200 into a voltage and current measuring instrument.

Specifications :

Voltage source up to 32 V and current source up to 200 mA
51/2-digit, 120000-count output resolution
Voltage and current simple monitoring feature (optional)
Programmable output up to 10,000 points
Built-in USB mass storage device
Channel expansion through synchronous operation

Accurate and Stable Output

This DC Voltage/Current Source provides highly stable and accurate output, with line and load regulation better than 0.05%. The digital LED display ensures precise voltage and current readings, supporting calibration and testing processes in both industrial and educational laboratories.

Enhanced Safety Features

Safety is paramount with built-in automatic overload protection, fuse-protected circuitry, and a dedicated insulation box. The 4mm safety sockets and ventilated body further reduce risks during prolonged usage, while the corrosion-resistant finish adds to the devices durability.

User-Friendly Design

Designed for convenience, the table-top mount and powder-coated front panel make handling and operation straightforward. Its marked scale and banana plug compatibility streamline connections and adjustments, supporting efficient workflows for dealers, importers, and end-users alike.

FAQs of DC Voltage/Current Source:

Q: How do you connect the DC Voltage/Current Source for laboratory testing purposes?

A: To connect the source, use banana plugs or 4mm safety sockets to attach your test leads to the output terminals. Ensure the unit is plugged into a 230V AC mains supply, and always verify that the insulation box is properly in place for added safety during operation.

Q: What benefits does the automatic overload protection provide during use?

A: Automatic overload protection helps prevent device or circuit damage by instantly cutting off the output when excessive current or load is detected. This feature secures both the equipment and the user, allowing for worry-free testing and calibration in sensitive environments.

Q: When is it advisable to switch between constant voltage and constant current operating modes?

A: Switch to constant voltage mode when you need a steady voltage supply regardless of load changes, such as powering electronic components. Use constant current mode when a fixed current is required, for example, charging batteries or operating devices that need precise current control.

Q: Where can this DC Voltage/Current Source be utilized effectively?

A: This unit is ideal for laboratory testing, educational demonstrations, and industrial calibration. Its robust build and accurate regulation suit universities, research institutes, manufacturing facilities, and training labs across India.

Q: What process ensures measurement accuracy in this voltage/current source?

A: Measurement accuracy is maintained by advanced line and load regulation (<0.05%) and a digital LED display, which provides real-time precise readings. The internal circuit design and fuse-protected components ensure stability and reliability during extended use.

Q: How does the corrosion resistant coating benefit long-term usage?

A: The corrosion-resistant coating protects the mild steel body from oxidation and chemical exposure, extending the equipments lifespan. It ensures safe operation in varying atmospheric and laboratory conditions, making it suitable for frequent and rigorous use.
